توضیحات

مولتی متر هولدپیک HP-90D

مولتی متر هولدپیک

مدل HP-90D

سایت سازنده محصول

HoldPeak 90 Series

MODEL: HP-90D

Product features
Shipped from USA and fulfilled by Amazon. Measurement of AC and DC voltage, DC current, resistance, capacitance, frequency, temperature, battery measurement, transistor HFE, diode test and on-off test,20A MAX FUSED,Temperature. 2000 manual counting range and medium-sized portable digital multimeter Operation manual
Features Data Hold function
Manual-ranging scales make electronic measurements much easier and a breeze
Comes with a super large Backlit LCD display which is visible in low light
Automatically enters sleep mode after 15 minutes of inactivity of rotary switch and buttons for saving power
Product description

The HOLDPEAK 90D Manual Ranging Multimeter is designed for both commercial and residential applications. It is an manual ranging meter for measuring AC/DC current and voltage, resistance, capacitance, frequency, temperature in commercial, home repair, automotive and electrical testing applications. It comes with non-contact voltage detection, a bright large backlit LCD display and auto power-off feature and also features Data Hold.

Specifications
Safety/Compliances: IEC61010 CAT.III 1000V, CAT.IV 600V overvoltage and double insulation standard
Display: 1999, analogue bar graph 41 segments
Range selection: Manual
Overload display: Display OL
DC voltage: 200mV/2/20/200V (¡À۰.۵%), ۱۰۰۰V (¡À۱.۵%)
AC voltage: 20V/200V (¡À۱.۵%), ۷۵۰V (¡À۲.۵%)
DC current: 2mA/20mA (¡À۰.۸%), ۲۰۰mA (¡À۱.۲%), ۲۰A (¡À۲.۰%)
AC current: 2mA (¡À۱.۰%), ۲۰۰mA (¡À۲.۰%), ۲۰A (¡À۳.۰%)
Capacitance: 2000pF/20nF/200nF/2uF (¡À۲.۵%), ۰ – ۱۰۰uF (¡À۲.۵%), ۱۰۰ – ۲۰۰uF (¡À۶.۰%)
Resistance: 200ohm (¡À۱.۲%), ۲k/20k/200kohm (¡À۰.۸%), ۲M/20Mohm (¡À۲.۵%)
Frequency range: 200kHz (¡À۳.۰%)
hFE: Yes
Diode test: Yes
Continuity test: Yes
Non-contact voltage detection: Yes
Dimensions: 6.6¡± x 3.48 x 2.36
Power: 9V 6F22 battery
Weight: 0.71 lb
