• DC voltage range is also available especially for checking emergency battery operated power supply.
• Tear drop shaped transformer jaws for ease of use.



AC A	۶/۱۵/۶۰/۱۵۰/۳۰۰A ±۳% of FS
AC V	۱۵۰/۳۰۰/۶۰۰V ±۳% of FS
DC V	۶۰V ±۳% of FS
Ω	۱/۱۰kΩ (۲۵/۲۵۰Ω mid-scale) ±۲% of scale length
Temperature	Note: The MODEL2608A includes a temperature measurement scale, but it is not available for new customers due to the discontinue of the Temperature Probe 7060.
Conductor size	Ø۳۳mm max.
Frequency response	۵۰Hz/60Hz
Applicable standards	IEC 61010-1 CAT III 300V Pollution Degree 2 IEC 61010-2-031 IEC 61010-2-032
Power source	R6 (AA) (1.5V) × ۱
Dimensions	۱۹۳(L) × ۷۸(W) × ۳۹(D)mm
Weight	۲۷۵g approx.
Included Accessories	۷۰۶۶A (Test leads) ۸۹۲۳ (Fuse [0.5A/600V]) × ۲ ۹۰۹۷ (Carrying case) R6 (AA) × ۱ Instruction Manual
Optional Accessories	۷۰۶۰ (Temperature probe) ۸۰۰۸ (Multi-Tran)
